GP146 Tri Axle
Model Details
Sean Hogan Trailers presents the Ifor Williams GP146 TRI general duty trailer for sale in Galway. the largest plant trailer in the Ifor Williams range. The GP146 Tri Axle has a big 6.47 meters of overall length to provide for the toughest of jobs. This solid build tri-axle can transport general plant machinery up to 3500 kg in weight and has a width of 2.3 meters. GP Plant Trailers are fitted with either a full width ramp or hinged skids as standard.
The GP146 TRI is widely acknowledged as one of the toughest plant trailers in the industry, with an open rectangular steel framework, integral with the chassis. GP models are fitted with a tough resin-coated plywood platform.
Other options include factory fitted aluminium treadplate floor covering, bolt on ramp knife edge and 1.8m/6’ skids or ramp in place of the standard size of 1.2m/4’. The Ifor Williams GP models are fitted with integrated ramp or skid supports. This standard feature ensures trailers are supported whilst being loaded without the need to deploy prop stands.
Specification
| Model | Tyres | Gross Weight | Unladen Weight | Internal Length | Internal Width | Overall Length | Overall Width |
|---|---|---|---|---|---|---|---|
| GP106 Skids | 155/70R12C | 3500kg | 705kg | 3.06m/10′ | 1.78m/5’10” | 5.25m | 2.30m |
| GP106 Ramp | 155/70R12C | 3500kg | 720kg | 3.06m/10′ | 1.78m/5’10” | 5.25m | 2.30m |
| GP126 Skids | 155/70R12C | 3500kg | 780kg | 3.66m/12′ | 1.78m/5’10” | 5.85m | 2.30m |
| GP126 Ramp | 155/70R12C | 3500kg | 795kg | 3.66m/12′ | 1.78m/5’10” | 5.85m | 2.30m |
| GP126 Skids Tri Axle | 155/70R12C | 3500kg | 890kg | 3.66m/12′ | 1.78m/5’10” | 5.85m | 2.30m |
| GP126 Ramp Tri Axle | 155/70R12C | 3500kg | 905kg | 3.66m/12′ | 1.78m/5’10” | 5.85m | 2.30m |
| GP146 Skids Tri Axle | 155/70R12C | 3500kg | 915kg | 4.28m/14′ | 1.78m/5’10” | 6.40m | 2.30m |
| GP146 Ramp Tri Axle | 155/70R12C | 3500kg | 930kg | 4.28m/14′ | 1.78m/5’10” | 6.47m | 2.30m |
